Shop by Category

Optics

  • Vortex Diamondback HP 4-16x42 Riflescope BDC
The Diamondback HP (High Performance) riflescope offers a full-on array of features that discerning hunters are sure to appreciate. Optically, these scopes hit the proverbial mark. XD extra-low dispersion glass increases resolution and colour fidelity while XR fully multi-coated lenses maximize every minute of shooting light. The side focus/parallax adjustment is easily accessible while keeping a trim profile and allowing optimal mounting height. And, with a 4x zoom range, the Diamondback HP offers highly versatile magnification.

SKU	VT-DBK-10019
Magnification	4 – 16
Objective Lens Diameter	42 mm
Eye Relief	4.0 inches
Field of View	23.8–6.1 feet/100 yards
Tube Size	1 inch
Turret Style	Capped
Adjustment Graduation	1/4 MOA
Travel per Rotation	15 MOA
Max Elevation Adjustment	80 MOA
Max Windage Adjustment	80 MOA
Parallax Setting	30 yards to infinity
Length	12.5 inches
Weight	18 ounces
Riflescope Manual (.pdf)	Download PDF
Reticle Manual (.pdf)	Download PDF
Included in the Box
4-inch sunshade
Protective lens caps
Lens cloth


VIP Unconditional Lifetime Warranty

Lengths
L1	L2	L3	L4	L5	L6
12.5	1.9	1.9	5.2	3.7	3.6
Heights
H1	H2
2.0	1.69
Dimensions measured in inches.

Optical Features
XD Lens Elements	Extra-low dispersion (XD) glass increases resolution and colour fidelity, resulting in crisp, sharp images.
XR Fully Multi-Coated	Proprietary coatings increase light transmission with multiple anti-reflective coatings on all air-to-glass surfaces.
Second Focal Plane Reticle	Scale of reticle maintains the same ideally-sized appearance. Listed reticle subtensions used for estimating range, holdover and wind drift correction are accurate at the highest magnification.
Construction Features
Tube Size	1-inch diameter.
Single-Piece Tube	Maximizes alignment for improved accuracy and optimum visual performance, as well as ensures strength and waterproofness.
Aircraft-Grade Aluminum	Constructed from a solid block of aircraft-grade aluminum for strength and rigidity.
Waterproof	O-ring seals prevent moisture, dust and debris from penetrating the riflescope for reliable performance in all environments.
Fogproof	Argon gas purging prevents internal fogging over a wide range of temperatures.
Shockproof	Rugged construction withstands recoil and impact.
Hard Anodized Finish	Highly durable low-glare matte finish helps camouflage the shooter's position.
Precision-Glide Erector System	Uses premium components in the zoom lens mechanism to ensure smooth magnification changes under the harshest conditions.
Capped Reset Turrets	Allow re-indexing of the turret to zero after sighting in the riflescope. Caps provide external protection for turret.
Side Focus	Adjustment located on riflescope's left side and is easily accessible from shooting position. Provides optimal image focus and parallax removal.
Internal Mechanism Design Features
Precision-Glide Erector System	Uses premium components in the zoom lens mechanism to ensure smooth magnification changes under the harshest conditions.
Convenience Features
Fast Focus Eyepiece	Allows quick and easy reticle focusing. Vortex Diamondback HP 4-16x42 Riflescope BDC

    Vortex Diamondback HP 4-16x42 Riflescope BDC

    Vortex Diamondback HP 4-16x42 Riflescope BDC The Diamondback HP (High Performance) riflescope offers a full-on array of features that discerning hunters are sure to appreciate. Optically, these scopes hit the proverbial mark. XD extra-low...

    $499.99
    Add to Cart
  • Description
Made in America, Talley Manufacturing’s CZ Picatinny Rails, designed to fit CZ Rimfire Rifle (Models 452 American, 452 European, 455, 457, and 513), are machined entirely from high grade 7000 series alloy and protected with a hard-coat anodizing to 65 Rockwell ensuring the craftsmanship of these Picatinny rails last the lifetime of your firearm. These CZ Picatinny Rails are all designed and manufactured with precision to fit your firearm with the industry’s tightest manufacturing tolerances.  These CZ Pic Rails provide a mounting platform for all optics mounts that have been designed in accordance with the MIL-STD-1913 Pic Rail specifications, to include all Talley Picatinny scope mounts.



Whether you are looking for a tactical scope ring, a modern sporting ring or our traditional scope ring with a Picatinny mounting system, Talley MFG has Pic Rails for all applications and firearms enthusiast.



American Made, Lightweight 7000 series Aluminum Alloy
Fully CNC Machined
Hard-coat anodizing to 65 Rockwell
Designed in accordance with the MIL-STD-1913 Pic Rail specifications
Available in 0 and 20MOA.
This CZ Scope Base includes nylon tipped tension screws.
Designed to fit CZ Rimfire rifles; CZ 452 American, CZ 452 European, CZ 453, CZ 455, CZ 457, AND CZ 513
Click here for all CZ options.


CZ Picatinny Rail  – CZ 457 Picatinny Rail Product Dimensions and Weights
Action / MOA	Rear Height1	Hole2 1 ↔ 2	Hole 2 ↔ 3	Hole 3 ↔ 4	Front Height3	Overall Length	Weight
Standard	.250″	2.36″	1.8″	1.07″	.250	5.37″	1.2oz.
20MOA	.278″	2.36″	1.8″	1.07″	.250″	5.37″	1.3oz.


CZ 452 American, CZ 452 European, CZ 453, CZ 455, AND CZ 513 Picatinny Rail Product Dimensions and Weights
Action / MOA	Rear Height1	Front Height3	Overall Length	Weight
Standard	.250″	.250	4.6″	1.0oz.
20MOA	.274″	.250″	4.6″	1.1oz.
1 The Rear height is measured from the top of the action to the top of the rail.

2 Hole 1 location is closest to the shooter and hole 4 location is closest to the muzzle. Hole spacing measured center to center.

3 The Front Height is measured from the top of the action to the top of the rail.



Torque Recommendations?
CZ Picatinny Rail tension screws to the Action: There are no torque specs for the use of these nylon tip screws in the CZ pic rail. These nylon tipped grub screws are designed to create tension between the CZ Scope Base and action without marring the surface.  They are designed for tension only and should be “snug”.


THE TALLEY GUARANTEE

NOTHING IS TOUGHER THAN A TALLEY
The Talley Guarantee: At Talley Manufacturing, we place our customers first. All our products carry a money back guarantee. If you are not completely satisfied, we make sure you will be. We want you to know you’ve just purchased the best. Talley Picatinny Rail For CZ 457 Rifle

    Talley Picatinny Rail For CZ 457 Rifle

    Description Made in America, Talley Manufacturing’s CZ Picatinny Rails, designed to fit CZ Rimfire Rifle (Models 452 American, 452 European, 455, 457, and 513), are machined entirely from high grade 7000 series alloy and protected with a hard-coat...

    $94.99
    Add to Cart
  • Five Thermal Color Palettes
The Shade Thermal offers users unique green hot, rainbow, and magenta color palettes in addition to black hot and white hot for added background contrast, eye comfort, and more precise heat detection.

Features
256x192 Thermal Resolution
Lightweight and Compact
OLED Display
5 Color Palettes
9 Reticle Colors
10 Reticles
5 Weapon Profiles
Built-in Recording w/ Sound
Shade Thermal Riflescope


SPECIFICATIONS	SM17004
Shade 2-16x15	SM17005
Shade 3.5-28x30
Sensor Resolution (pixels)	256x192
Sensor Type	Thermal Sensor
Display Resolution (pixels)	1280x720
Display Type	FLCOS LCD
Magnification (x)	2x Optical	3.5x Optical Shade 256 2-16x15 Mini Thermal Rifle Scope

    Shade 256 2-16x15 Mini Thermal Rifle Scope

    Five Thermal Color Palettes The Shade Thermal offers users unique green hot, rainbow, and magenta color palettes in addition to black hot and white hot for added background contrast, eye comfort, and more precise heat detection...

    $1,089.99
    Add to Cart
  • Each Weaver base is machined to tight tolerances for a custom fit. These aluminum bases offer maximum strength for rings to hold tight.

Machined to tight tolerances for a custom fit
Offer the rock solid Weaver cross-lock design to fit a variety of rings
*(See Mount Application Chart for firearm/base matching)

    Weaver Top Mount Base #99

    Each Weaver base is machined to tight tolerances for a custom fit. These aluminum bases offer maximum strength for rings to hold tight. Machined to tight tolerances for a custom fit Offer the rock solid Weaver cross-lock design to fit a variety of...

    $44.99
    Add to Cart
  • Enjoy optical superiority with our new Tactical Multi-Slot Bases. These Picatinny bases are designed for specific models of firearms and provide an additional 1 inch of forward length for more mounting options. Manufactured from 6061 T6 aluminum and protected by a matte, Type III hard coat anodized finish, these multi-slot bases are compatible with Picatinny or Weaver style rings. An integral recoil lug, no slip/strip Torx screws round out the features of these tactical bases. Fits Rem 700 LA.

    Weaver Tactical Extended Multi-Slot Base #99501

    Enjoy optical superiority with our new Tactical Multi-Slot Bases. These Picatinny bases are designed for specific models of firearms and provide an additional 1 inch of forward length for more mounting options. Manufactured from 6061 T6 aluminum and...

    $74.99
    Add to Cart
  • There’s no longer a need to search for front and rear bases for your most popular firearms. Weaver® Base Pairs feature tough, lightweight aluminum construction to hold up to the most powerful recoil. The Weaver cross lock design means a tight, secure fit on your firearm. These bases accept all Weaver top mount cross lock rings.

Also fits the following firearms: Browning – Bar, Bar II, Mark II, BLR Lightning(Lever), BPR

Contains 2 each 54m bases.

    Weaver Classic Aluminum Base Pair #54Mx2

    There’s no longer a need to search for front and rear bases for your most popular firearms. Weaver® Base Pairs feature tough, lightweight aluminum construction to hold up to the most powerful recoil. The Weaver cross lock design means a tight,...

    $24.99
    Add to Cart
  • Weaver Top Mount Aluminum Bases

Experience unmatched precision and reliability with the Weaver Top Mount Aluminum Bases. Machined to exacting tolerances, these bases deliver a custom fit and ensure maximum strength for securing your riflescope rings.

Key Features:

Custom Precision Fit: Crafted with tight machining tolerances to provide a seamless fit on your firearm.
Rock-Solid Cross-Lock Design: Features Weaver's trusted cross-lock design for secure compatibility with a variety of riflescope rings.
Proudly Made in the USA: Precision-manufactured to deliver the highest quality and reliability.
Rem 700 S/A

    Weaver Classic Aluminum Base #97

    Weaver Top Mount Aluminum Bases Experience unmatched precision and reliability with the Weaver Top Mount Aluminum Bases. Machined to exacting tolerances, these bases deliver a custom fit and ensure maximum strength for securing your riflescope rings...

    $48.99
    Add to Cart
